Atlas AD Elevator Buckets
4B Braime AD400 Atlas AD Elevator Buckets
This industrial duty super tough elevator bucket is manufactured from “Nyrim” which is a high-grade nylon/rubber reaction molding. These unique properties offer the elevator bucket the ability to withstand maximum resistance to impact and abrasion. Can be used with many abrasive and corrosive industrial materials, such as: AGGREGATES, CEMENT, GYPSUM, COAL, SAND, ETC. The “AD” elevator bucket can be used with elevator belting or chain. The reduced weight of the elevator bucket, compared to a steel fabricated type, enables extended chain life. The “Nyrim” material is corrosion resistant which also allows for longer bucket life. The “AD” elevator bucket design allows for high capacity capabilities.
Description
Additional information
| Brand |
|---|
UZYSKAJ CENĘ
Aby otrzymać propozycję, wyślij swoją aplikację na adres info@dystrybutor-przemyslowy.pl i określ wymagane stanowiska oraz dane firmy.
Specification
| Nominal size | A | B | C | D | T | Weight | Capacity (L) | Capacity (L) | |||
| Atlas AD bucket | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (kg) | Z2 (total) | Z3 (water) | ||
| AD300 | 300 x 200 | 361 | 202 | 215 | 111 | 14 | 43 | 1.7 | 6.75 | 4.135 | |
| AD400 | 400 x 224 | 424 | 247 | 286 | 156 | 11 | 39 | 2.75 | 14.33 | 9 | |
| AD500 | 500 x 250 | 524 | 274 | 321 | 174 | 12 | 39 | 3.8 | 23.2 | 15 | |
| AD630 | 630 x 280 | 654 | 306 | 363 | 196 | 12 | 39 | 6.8 | 36 | 23.4 | |
