Coaxial Pneumatic Valves in Stainless Steel
Valves for applications for Air, Water, neutral or slightly corrosive fluids, neutral Gases, Vacuum 740 mm Hg.
General Information:
Body in Stainless Steel CF8
Double and Single Effect piston with spring return
ON/OFF Function
Diagram: Double Effect or Normally Closed
Control Fluid: Dry or lubricated compressed air
Options:
Namur control solenoid valve, direct assembly
Body in Stainless Steel CF8M – A316
Tightening seal in EPDM
Evian 2600 Pneumatic Valve
Pneumatic Threaded G 3/8″ – 2″
Description
Additional information
| Brand |
|---|
UZYSKAJ CENĘ
Aby otrzymać propozycję, wyślij swoją aplikację na adres info@dystrybutor-przemyslowy.pl i określ wymagane stanowiska oraz dane firmy.
Specification
Valve Body: Stainless Steel CF8 (A304 SS)
Piston Cap: Stainless Steel CF8 (A304 SS)
Tightening Disc: FKM
Fitting Size: Bevel Threaded G from 3/8" to 2"
Diameters: From 13 to 45 mm
Rated pressure: PN 16
Control Fitting: 1/8"
Control Pressure: from 3 to 8 bar
Viscosity of the Fluid: 500 Cst. max.
Temperatures of the Fluid: From -20° C to +150° C for FKM tightness
Ambient Temperature: From -20° C to + 80° C
