HazardMon.com®
4B Braime HazardMon.com®
HazardMon.com® is a secure cloud based hazard monitoring solution providing status notifications and data logging for bucket elevators and conveyors. Live system status, graphs and historical data can be viewed on any web-enabled device (smartphone, tablet PC, desktop or laptop computer). Emails can be sent to notify users whenever a change in the system’s health is detected. An automated maintenance feature allows site operators to verify that all sensors on the system are operational and working correctly.
Hazardmon.com works in conjunction with 4B’s Watchdog Super Elite™ and T500 Elite Hotbus™ control systems for bucket elevators and conveyors. Both multi-function systems are specially designed to monitor equipment for belt misalignment, belt speed, continuous bearing temperature, pulley alignment, level and plug conditions.
Description
Additional information
| Brand |
|---|
UZYSKAJ CENĘ
Aby otrzymać propozycję, wyślij swoją aplikację na adres info@dystrybutor-przemyslowy.pl i określ wymagane stanowiska oraz dane firmy.
Specification
Related products
4B Braime ADB819V3AI/D2 ADB Series Bearing Sensors
The ADB series have been designed to allow the depth of the sensor to be adjustable depending on your application. A number of versions are available with probe lengths of 50, 100, 200 and 300 mm. The sensors screw directly into a bearing housing through a 1/4” BSPT threaded grease zerk. Each sensor is fitted with a grease zerk to allow lubrication of the bearing without the need for removal of the sensor. The ADB series have NTC or PT100 type thermistors which allow for continuous temperature monitoring.
The sensor is supplied with a 3m attached cable and can be connected to a PLC or to a hazard monitoring system, such as 4B’s Watchdog Super Elite, T500 Hotbus Elite or T400 NTC Elite. The connections are not polarity sensitive therefore special connection requirements are eliminated, and the cable can be extended in the field.
4B Braime ADB819V3AI/D12 ADB Series Bearing Sensors
The ADB series have been designed to allow the depth of the sensor to be adjustable depending on your application. A number of versions are available with probe lengths of 50, 100, 200 and 300 mm. The sensors screw directly into a bearing housing through a 1/4” BSPT threaded grease zerk. Each sensor is fitted with a grease zerk to allow lubrication of the bearing without the need for removal of the sensor. The ADB series have NTC or PT100 type thermistors which allow for continuous temperature monitoring.
The sensor is supplied with a 3m attached cable and can be connected to a PLC or to a hazard monitoring system, such as 4B’s Watchdog Super Elite, T500 Hotbus Elite or T400 NTC Elite. The connections are not polarity sensitive therefore special connection requirements are eliminated, and the cable can be extended in the field.
4B Braime ADB819V3AI ADB Series Bearing Sensors
The ADB series have been designed to allow the depth of the sensor to be adjustable depending on your application. A number of versions are available with probe lengths of 50, 100, 200 and 300 mm. The sensors screw directly into a bearing housing through a 1/4” BSPT threaded grease zerk. Each sensor is fitted with a grease zerk to allow lubrication of the bearing without the need for removal of the sensor. The ADB series have NTC or PT100 type thermistors which allow for continuous temperature monitoring.
The sensor is supplied with a 3m attached cable and can be connected to a PLC or to a hazard monitoring system, such as 4B’s Watchdog Super Elite, T500 Hotbus Elite or T400 NTC Elite. The connections are not polarity sensitive therefore special connection requirements are eliminated, and the cable can be extended in the field.
4B Braime ADB810V3AI/D12 ADB Series Bearing Sensors
The ADB series have been designed to allow the depth of the sensor to be adjustable depending on your application. A number of versions are available with probe lengths of 50, 100, 200 and 300 mm. The sensors screw directly into a bearing housing through a 1/4” BSPT threaded grease zerk. Each sensor is fitted with a grease zerk to allow lubrication of the bearing without the need for removal of the sensor. The ADB series have NTC or PT100 type thermistors which allow for continuous temperature monitoring.
The sensor is supplied with a 3m attached cable and can be connected to a PLC or to a hazard monitoring system, such as 4B’s Watchdog Super Elite, T500 Hotbus Elite or T400 NTC Elite. The connections are not polarity sensitive therefore special connection requirements are eliminated, and the cable can be extended in the field.
4B Braime WDB74V3AI WDB7 Lug Style Bearing Sensors
The WDB7 series is a lug style NTC thermistor or platinum RTD (PT100) type for continuous temperature monitoring. It is designed to bolt directly onto a bearing housing, motor, gearbox, or machine casing. The mounting hole is M8 which can be drilled out up to M10 diameter. The sensor can be connected to a PLC or to a hazard monitoring system, such as 4B’s T500 Hotbus Elite, Watchdog Super Elite, or T400 Elite. The connections are not polarity sensitive therefore special connections requirements are eliminated. The WDB7 series is approved for use in ATEX and IECEx Zone 20 dust hazard locations.
4B Braime MDB813V3AI MDB Series Bearing Sensors
The MDB series is a range of bearing sensors manufactured to screw directly into a bearing housing through the existing 1/4” BSPT threaded grease zerk (can be installed in 1/8” NPT grease zerk fitting with an adapter). Each sensor is fitted with a grease zerk to allow lubrication of the bearing without the need for removal of the sensor. The sensor is fitted with a M12 connector for use with a separately supplied cable and socket assembly which can be attached connected directly to a PLC or to a hazard monitoring system, such as 4B’s T500 Hotbus Elite, Watchdog Super Elite, or T400 / T400 NTC Elite. The connections are not polarity sensitive therefore special connection requirements are eliminated. Four versions are available, a NTC thermistor model or PT100 type for continuous temperature monitoring, and PTC or Contact thermistor models with five trip points (60°C, 70°C, 80°C).
4B Braime MDB812V3AI MDB Series Bearing Sensors
The MDB series is a range of bearing sensors manufactured to screw directly into a bearing housing through the existing 1/4” BSPT threaded grease zerk (can be installed in 1/8” NPT grease zerk fitting with an adapter). Each sensor is fitted with a grease zerk to allow lubrication of the bearing without the need for removal of the sensor. The sensor is fitted with a M12 connector for use with a separately supplied cable and socket assembly which can be attached connected directly to a PLC or to a hazard monitoring system, such as 4B’s T500 Hotbus Elite, Watchdog Super Elite, or T400 / T400 NTC Elite. The connections are not polarity sensitive therefore special connection requirements are eliminated. Four versions are available, a NTC thermistor model or PT100 type for continuous temperature monitoring, and PTC or Contact thermistor models with five trip points (60°C, 70°C, 80°C).
